SOTION Dragon 01 hub motor 50kw

50kW Rated | 100kW Peak | 12-Inch Wheel | 120H Magnets



The SOTION Dragon 01 is a heavy-duty rear hub motor engineered for extreme performance applications. With 120H-grade high-temperature magnets and a compact 12-inch (φ330×410 mm) form factor, it delivers exceptional torque and sustained high output without sacrificing efficiency.



Technical Specifications:



Rated Voltage: 96V



Rated Power: 50 kW



Peak Power: 100 kW



Rated Torque: 170 N·m



Peak Torque: 1000 N·m @ 4500A



Rated Speed: 1400 rpm



Peak Speed: 3500 rpm



Number of Pole Pairs: 16



Weight: 54.55 kg



Efficiency: ≥ 93%



Insulation Class: F (155°C)



Position Sensor: Dual Hall Sensors



Temperature Sensor: NTC



Color: Matte Black



Installation: Rear hub drive





Performance Highlights:



Massive Torque Output: Up to 1000 N·m peak torque for explosive acceleration.



High Efficiency: Sustains over 93% efficiency in the optimal torque-speed range.



Compact but Powerful: 12-inch wheel size with performance that rivals larger mid-drive motors.



Thermal Stability: 120H magnets resist demagnetization even under extreme heat.



Quiet Operation: Direct-drive hub eliminates chains and gears for silent, low-maintenance performance.





Ideal Applications:



High-performance electric motorcycles



Compact EV conversions



Off-road and racing builds



Industrial and heavy-duty transport





Why Choose the Dragon 01?

The efficiency map shows a wide high-performance band, maintaining above 90% efficiency across most of the usable torque range. Combined with its extreme peak torque capability and compact size, the Dragon 01 is perfect for builders who demand both brute power and reliability.



📦 Worldwide shipping available – Contact us for pricing, controller pairing, and custom configurations.
